Omniscan 450 SS (300m rated)

453,167円

送料についてはこちら

水中ドローン社公式ストアにお越しくださり、誠にありがとうございます。 <<産業用水中ドローンの国内トッププロバイダー>> “夢と感動の水中テクノロジー企業”水中ドローン社 <<米Blue Robotics社の日本における正規の販売店なのでご購入後も安心>> ※15時までのご注文確定で当日発送(日曜・祝日を除く)いたします。ご注文急増時は翌日以降の発送となる場合がございます。お急ぎの場合は電話・メールでお問い合わせください。 The Omniscan 450 SS is tailored for side-scan applications. It has a longer transducer which gives 50% better angular resolution and 150m maximum range. For scanning both sides simultaneously, order quantity 2. SonarView integrates both devices together as if they were a single system. <Product Description> As the ROV or surface vessel moves, SonarView “paints” the image of the scanned area of the sea floor giving excellent situational awareness in the murkiest conditions. In the case of a surface vessel with GPS or an ROV with DVL, scanning is translational as well as rotational. A key feature of the Omniscan 450 is its integration via SonarView with the vehicle's MAVLINK data stream. Using the vehicle's attitude and location information, SonarView displays each ping in its correct absolute orientation and position. The Omniscan 450 SS transducer is rated to 300m operating depth. Two units of the Omniscan 450 SS can be combined in SonarView for the conventional side-scan application in which both sides are scanned simultaneously. The electronics module must be mounted in the vehicle’s water tight enclosure. ※Although the model designations specify Forward Scanning and Side Scanning, in reality either one can be used for either application. The real difference is in the transducer and the packaging. SKU:OS450SS <Contents> ・1 x Omniscan 450 SS Transducer with 2m shielded cable ・1 x Omniscan 450 electronics module ・1 x 1m ethernet cable with 4-pin JST-GH connectors ・1 x JST-GH to RJ45 (female) Adapter <Guides> SonarView User Manual → https://docs.ceruleansonar.com/sonarview Omniscan 450 User Manual → https://docs.ceruleansonar.com/omniscan-450-user-manual Introducing Omniscan → https://blog.ceruleansonar.com/introducing-omniscan/ Omniscan STEP files → https://www.dropbox.com/sh/ek2gfy3msjj7b1r/AABqpLrAVb6MBFq33t3zgIKMa?dl=0
