Cerulean Omniscan 450 Side Scan Sonar

1,084,842円

送料についてはこちら

水中ドローン社公式ストアにお越しくださり、誠にありがとうございます。 <<産業用水中ドローンの国内トッププロバイダー>> “夢と感動の水中テクノロジー企業”水中ドローン社 <<米Blue Robotics社の日本における正規の販売店なのでご購入後も安心>> ※15時までのご注文確定で当日発送(日曜・祝日を除く)いたします。ご注文急増時は翌日以降の発送となる場合がございます。お急ぎの場合は電話・メールでお問い合わせください。 This sonar seamlessly integrates with the BlueBoat to provide side scan sonar imaging to help you locate and identify underwater objects and map the seafloor. It comes ready-to-use on the BlueBoat and uses the Cerulean SonarView application in BlueOS for real time data visualization. Requires an Ethernet Switch for use on the BlueBoat. SKU: BR-102105 HS Code: 9015.80.8080 <Product Description> The Cerulean Omniscan 450 SS is a side scan sonar ready to integrate on the BlueBoat for real time imaging of the seafloor. It’s the perfect tool for hunting for shipwrecks, marine archeology, ecosystem mapping, and search and recovery. A side scan sonar is a type of imaging sonar that allows you to quickly collect imagery of the seafloor to map large areas. The side scan transducers have a narrow, tall beam shape so that when they are mounted to either side of the boat, they have a full 180 degree view under the boat. When scanning, the transducers emit an acoustic pulse and then record the response as echoes return from the seafloor. That creates a slice of an image and as the boat moves forward, the image is filled in. This side scan sonar uses 450 kHz transducers, which provide a 150 meter range with detailed resolution. Using Cerulean’s SonarView application, which is available as a BlueOS Extension, you can visualize the side scan data in real time. Unlike most side scan sonars, which require post processing to georeference the data and create a map, SonarView processes data in real time to make a complete picture of a seafloor area. SonarView has bottom detection and removal to remove the “blank” space in the middle of the side scan image, and is able to display the vehicle’s position in 3D. It also provides control of the sonar settings and logs data to be replayed later. As a BlueOS Extension, you can install SonarView with one click and stay up-to-date with the latest release and newest features. Check out the SonarView Demo to replay a log file and get an idea of the user experience. The Omniscan 450 SS was designed with the BlueBoat in mind and much of the prototype testing was done with a BlueBoat. It comes with everything needed for a clean integration including pre-installed WetLink Penetrators, transducer mounting brackets, cables, and hardware. The only additional item you’ll need is an Ethernet switch to provide connectivity for the sonar electronics. The sonar also works on the BlueROV2 if you wish to scan from a subsea vehicle and is rated to a depth of 300 meters. We don’t have an official integration guide for the BlueROV2, so you’ll have to figure out the details of where to mount the electronics inside the enclosure. Our integration guide shows how to install the sonar and covers basic usage in some example applications. If you have further questions or want to share your own results, check out our community forums. <Contents> ・2 x Cerulean Omniscan 450 SS transducer ・2 x Cerulean Omniscan 450 SS PCB ・2 x Cerulean Omniscan 450 SS transducer bracket (BR-102204) ・2 x Aluminum PCB standoff (BR-102498) ・Cerulean Omniscan integration cables and hardware kit ◦ 1 x BlueOS 128GB SD card for BlueBoat (BR-102293-002) ◦ 1 x Micro-Fit Ethernet cable, 1.1 m (BR-102172) ◦ 2 x Micro-Fit to JST GH cable, 0.32 m (BR-102122) ◦ 2 x E-Tray transducer cable (BR-102212) ◦ 2 x 2-position ferrules to ferrules power cable, 150 mm (BR-102196) ◦ 3 x 5A Mini Blade fuse (BR-101401-005) ◦ 4 x M5x18 socket head cap screw (BR-101191) ◦ 4 x #3×3/8″ button head thread forming screw (BR-101031) ◦ 8 x M3x8 socket head cap screw (BR-100989) ◦ 8 x 8.5″ cable tie (BR-102154) ◦ 4 x BlueBoat Hull Mount Bushing ◦ 4 x M6x20 socket head cap screw (BR-102241) ◦ 4 x M6 nylon insert lock nut (BR-101258) ◦ 2 x -117 bulkhead O-ring (BR-100635-117) ◦ 2 x M14 bulkhead nut (BR-100845) <Technical Details> - 3D Models OMNISCAN_450_SS_BR-102105 (.zip) → https://cad.bluerobotics.com/OMNISCAN_450_SS_BR-102105.zip - Revision History 13 December 2023 ・BR-102105 - Initial Release July 2023 ・Pre-orders opened <Guides> Integrating the Omniscan 450 SS on the BlueBoat → https://bluerobotics.com/learn/omniscan-450-ss-integration/
